型 号 MODEL
|
UTO-3L-B50
|
UTO-3L-B55
|
UTO-3L-B65
|
|
|
适用原料 SUITABLE MATERIAL
|
LDPE LLDPE HDPE
|
|
产品宽度 FILM WIDTH(mm)
|
800-1500
|
1200-2000
|
1600-2500
|
|
|
产品厚度 FILM THICKNESS(mm)
|
0.028-0.20
|
0.028-0.20
|
0.028-0.20
|
|
|
最大挤出量 MAX. OUTPUT(kg/hr)
|
220
|
290
|
380
|
|
|
挤出机/EXTRUDER
|
|
螺杆直径 SCREW DIAMETER(mm)
|
Aφ50 Bφ55 Cφ50
|
Aφ55 Bφ65 Cφ55
|
Aφ65 Bφ70 Cφ65
|
|
|
螺杆长径比 SCREW L/D RATIO
|
28:1
|
|
螺杆材料 SCREW MATERIAL
|
SACM-645/38 CRMOALA
|
|
料筒材料 CYLINDER MATERIAL
|
SACM-645/38 CRMOALA
|
|
料筒冷却 CYLINDER COOLING
|
370w×2/3
|
370w×2/3
|
550w×3/3
|
|
|
主机功率 DRIVING MOTOR(Kw)
|
A18.5 B22 C18.5
|
A22 B37 C22
|
A37 B45 C37
|
|
|
料筒温度控制 TEMPERATURE CONTROL
|
3×3
|
3×3
|
3×3
|
|
|
平均耗电量 AVERAGE POWER-CONSUME(Kw)
|
80
|
95
|
120
|
|
|
膜头/TYPE OF DIE
|
|
模 口 DIE SIZE(mm)
|
250/300
|
400
|
500
|
|
|
温度控制 TEMPERATURE CONTROL
|
4
|
|
风 环 AIR RING
|
1
|
|
风 机 AIR BLOWER(Kw)
|
7.5
|
11
|
15
|
|
|
引取装置/TAKE-UP UNIT
|
|
牵引辊宽 TAKE-UP ROLLER WIDTH
|
φ165×1600
|
φ190×2100
|
φ190×2600
|
|
|
上下可升降式 HEIGHT ADJUSTABLE TYPE
|
1000mm
|
|
引取速度 TAKE-UP SPEED(m/min)
|
5-60
|
5-60
|
5-60
|
|
|
引取电机功率 TAKE-UP MOTOR(Kw)
|
1.5
|
2.2
|
2.2
|
|
|
卷取装置/WINDING UNIT
|
|
表面摩擦式 WINDING TYPE
|
SURFACE FRICTION TYPE
|
|
卷取功率 WINDING MOTOR(N.m)
|
1.5
|
2.2
|
2.2
|
|
|
卷取速度 WINDING SPEED(m/min)
|
5-60
|
5-60
|
5-60
|
|
|
占地尺寸 OVERALL DIMENSION(LxWxH)
|
9.5×4.5×7.5m
|
10.5×5.0×9m
|
11.5×5.5×10m
|
|
