Model

UTO-45YT

UTO-50YT

UTO-55YT

Raw Materials

LDPE、HDPE、LLDEP

LDPE、HDPE、LLDEP

LDPE、HDPE、LLDEP

Screw Diameter.

45mm

50mm

55mm

Screw Ratio L/D

28: 1

28: 1

28: 1

Main Motor Power

7.5kw

11kw

15kw

Max.output

35kg/h

50kg/h

65kg/h

Die head Diameter.

Φ60、Φ80

Φ80、Φ100

Φ100、Φ125

Max.folding Width of film

600mm

800mm

1000mm

Thickness of film

0.01-0.10mm

0.01-0.10mm

0.01-0.10mm

Length Range of Printing

191-1200mm

191-1200mm

191-1200mm

Printing width

600mm

800mm

1000mm

Total Power

28kw

32kw

40kw

Weight

3.5T

4T

5T

Overall Dimensions

6000×2400×4000mm

6200×2600×4300mm

6400×2800×4800mm
